5HP / 5.5HP Control Panel, 460V 3-phase, with manual / automatic water level control

Tuhorse
SKU:
TCP55T460
US$229.00
US$339.00
(You save US$110.00 )
(1 review)
Weight:
21.00 LBS
Width:
20.00 (in)
Height:
14.00 (in)
Depth:
10.00 (in)
Condition:
New
Current Stock:

For use with a submersible deep well water pump. Supports 5.5HP three phase water pumps running on 460V

Features a full automatic mode with water level probes and manual mode.

     Model: TCP55T460

  • HP: 4 - 5.5HP
  • Voltage: 460V 3-Phase
  • Cycle: 60 Hz
  • Overload Protector: included, Maximum Amps 13A, adjustable range 9A to 13A
  • Phase Loss protection: included in auto mode
  • Water level probes: included
  • Micro Processor Control: yes
  • Housing Material: Steel
  • Knockout for wire: Two x 3/4"/1"/1.25" for power wires, One x 1/2" for sensor wire
  • Net weight: 7.7kg (17Lb)
  • Dimensions/Length:  44cm x 32cm x 20cm or 17-3/8" x 12-1/4" x 8"
  • Shipping Weight: 21 Lbs.  20"x14"x10"



More details:

* Steel Casing w/ lock and keys

* Manual mode controlling the motor On/Off for testing/diagnostic

* Also can be used with non-water-pump motors

* Water level probes are optional for installation, default bypassed

* Automatically controlling the motor by the probes' signal according to the water level in the well or in the cistern, or by other pilot device if used.

* Connection Terminals accept up to #4 AWG wire

* 3 Phase magnet relay switch

* Built-in overload protection with fine turn

* Phase-Loss protection (auto mode only)

* Voltage, Amperage meters. Working status LED indicators

* For indoor and under cover mounting





1 Year
