20HP Control Panel, 460V 3-phase, with manual / automatic water level control

SKU:
TCP200T460
US$289.00
US$439.00
(You save US$150.00 )
(No reviews yet) Write a Review
Weight:
22.00 LBS
Width:
19.00 (in)
Height:
14.00 (in)
Depth:
10.00 (in)
Condition:
New
Current Stock:

For use with a submersible deep well water pump. Supports 20HP three phase water pumps running on 460V.

Features a full automatic mode with water level probes and manual mode.



Model: TCP200T460

  • HP: 15HP - 20HP
  • Voltage: 460V Three Phase
  • Cycle: 60 Hz
  • Overload Protector: included, Maximum Amps adjustable
  • Phase Loss protection: included using auto mode
  • Water level probes: included
  • Micro Processor Control: yes
  • Housing Material: Steel
  • Knockout for wire: Two x 3/4"/1"/1.25" for power wires, One x 1/2" for sensor wire
  • Net weight: 10kg (22Lb)
  • Dimensions/Length:  44cm x 32cm x 20cm or 17-3/8" x 12-1/4" x 8"
  • Shipping Weight: 22 Lb.



More details:

* Steel Casing w/ lock and keys

* Manual mode controlling the motor On/Off for testing/diagnostic

* Can be used with non-water-pump motors

* Water level probes are optional for installation, default bypassed

* Automatically controlling the motor by the probes' signal according to the water level in the well or in the cistern, or by a pilot device if used.

* Connection Terminals accept up to #4 AWG wire

* 3 Phase magnet relay switch

* Built-in overload protection with fine turn

* Phase-Loss protection (auto mode only)

* Voltage, Amperage meters. Working status LED indicators

* For indoor and under cover mounting



1 Year
